| Model name | Pallet Fork PF5000 |
|---|---|
| Weight, lbs | 1675.8 |
| Weight, kg | 760 |
| Fork carriage class | class 4, A |
| Fork carriage width, inch | 78.7 |
| Fork carriage width, mm | 2000 |
| Fork edge length L, inch | 20,5/71,65/83,5 |
| Fork edge length L, mm | 1520/1820/2120 |
| Fork width/thickness, inch | 5,9x2,16 |
| Fork width/thickness, mm | 150х55 |
| Nominal distance of the center of gravity of the load Lp, inch | 19.7 |
| Nominal distance of the center of gravity of the load Lp, mm | 500 |
| Lifting Capacity, lbs | 11025 |
| Lifting Capacity, kg | 5000 |
| Fork Length (B), inch | 47,2 - 94,5 |
| Fork Length (B), mm | 1200 - 2400 |
| Applicability | BHL, Wheeled loaders, Telescopic handlers |
